MG995 Metal Gear Servo Motor 180 Degree

MG995 High-Torque Servo Motor (180° Rotation)

The MG995 Servo Motor is a high-torque rotary actuator widely used in robotics, RC vehicles, drones, robotic arms, and automation projects. It provides precise position control over a 180° rotation range, making it ideal for applications requiring accurate movement and reliable performance.

Designed with a robust dual ball-bearing mechanism, the MG995 delivers smooth operation, stable torque output, and improved resistance to shock and vibration. Its high torque capability makes it suitable for medium to heavy-load applications such as robotic joints, steering systems, and pan-tilt mechanisms.

Important Note

This MG995 model is a budget-friendly version and may contain plastic gears instead of metal gears. While it performs well in many applications, plastic gears may experience faster wear under continuous operation or high-load conditions compared to genuine metal-gear variants.

Key Features

• High-torque servo motor with 180° rotation
• Suitable for robotics, drones, RC vehicles, and automation projects
• Dual ball-bearing design for smooth and stable operation
• Precise position control and consistent torque output
• Shock-resistant construction
• Compatible with most microcontrollers and servo controllers
• Easy PWM control interface

Technical Specifications

• Operating Voltage: 4.8V – 7.2V DC
• Idle Current: 10mA
• No-Load Operating Current: 170mA
• Maximum Load Current: 1200mA
• Stall Torque:
  • 9.4 kg·cm @ 4.8V
  • 11 kg·cm @ 6V
• Operating Speed:
  • 0.20 sec/60° @ 4.8V
  • 0.16 sec/60° @ 6V
• Rotation Angle: 180°
• Dead Band Width: 5 μs
• Dimensions: 40.7 × 19.7 × 42.9 mm

Package Includes

• 1 × MG995 Servo Motor (180° Rotation)
